NIBCO INC N001166 TI8 1/2 Full Port Gate Valve

Product Description

The NIBCO INC N001166 TI8 1/2 Full Port Gate Valve is designed for various plumbing applications. This gate valve features a full port for maximum flow. The actuator type is handwheel, making it easy to operate.

• Nominal size: 1/2 inch
• Pressure rating: 200 psi
• Brass body with graphite/rubber softgoods

Product Highlights

The NIBCO INC gate valve is ideal for regulating flow in pipes and is suited for non-shock service applications.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Categories: Valves

Technical Specifications

• Actuator Type: Handwheel
• Body Material: Brass
• Domestic/Import: Import
• End Style: FNPT
• Hand Wheel Diameter: 2.13 inches
• Inlet to Outlet Length: 1.69 inches
• Nominal Size: 1/2 inch
• Port Type: Full
• Pressure Rating: 200 psi
• Series: TI-8
• Softgoods Material: Graphite/Rubber
• Top to Inlet Center: 2.83 inches
• Trim Material: Brass
