NIBCO H-16804W Forged DZR Brass Transition Fitting

Product Description

The NIBCO H-16804W is a forged DZR brass transition fitting intended for plumbing and heating applications. It operates as an adapter that allows connections between various piping systems. One end features a press connection, while the other end has an ASTM F1807 PEX connection. This fitting is suitable for both residential and commercial plumbing as well as heating systems. It is lead-free and meets NSF/ANSI standards.

• Press connection on one end.
• ASTM F1807 PEX connection on the other.
• Lead-free construction compliant with industry standards.

Product Highlights

The NIBCO H-16804W is designed for easy connections in plumbing and heating systems, ensuring reliable and safe operation.

Product Information

Standard Information

• Brand: NIBCO
• MPN: H-16804W

Technical Specifications

• Type: Adapter
• Fitting Type: Adapter (Press x Crimp)
• Connection Type: Press x ASTM F1807 PEX
• End Connection: Press x F1807 PEX
• Size: 1
• Material: Brass
• Body Material: EPDM
• Process: Forged
• Maximum Operating Pressure: 250 psi
• Pressure Rating: 250 PSI CWP
• Maximum Temperature: 250 °F
• Operating Temp Range: 0°F-250°F
• Application: Residential/Commercial Plumbing and Heating Systems
• Lead-Free: Yes
• Applicable Standard: NSF/ANSI 14/61/372, IGC 319
• Weight: 0.157 lb
• A: 1.96 in
