NIBCO 2020650HPC BenchPressG Repair Coupling 2 in Press Connection

Product Description

The NIBCO BenchPressG repair coupling, MPN 2020650HPC, is made from carbon steel and is designed for press connections. This two-inch coupling is ideal for repairing connections between two lengths of pipe without the need for threading. It comes equipped with a yellow HNBR O-ring and a stainless steel gripper ring, ensuring reliability and durability. When pressure is applied using a pressing tool, the O-ring secures tightly onto the pipe, providing a strong seal. This coupling is versatile and can be used in natural gas, compressed air, and fuel systems.

• Press connections available without a tube stop.
• Constructed with a yellow HNBR O-ring and a stainless steel gripper.
• Compatible with carbon steel pipe.

Product Highlights

This product is suited for various applications, including gas and air systems, ensuring effective performance across industries.

Product Information

Standard Information

• Brand: NIBCO
• MPN: 2020650HPC

Technical Specifications

• Sub Brand: BenchPressG
• Model: PCH201
• Type of Fitting: Coupling
• Type of Coupling: Repair (No Stop); Straight Size
• Nominal Size: two inches
• Connection Type: Press
• Material: Carbon Steel
• Length: four point eight six inches
• Maximum Pressure: two hundred PSI
• Temperature Rating: -20 to 250 degrees Fahrenheit
• System Use: Natural Gas, Compressed Air, Diesel Fuel, Liquid Propane
