Multiple 719030623 MWC A30009PB 18/3 Unshielded Stranded Plenum White 1000 FT Pull Box

Product Description

The Multiple 719030623 MWC A30009PB is an unshielded electronic plenum cable designed for various applications. This cable features three conductors and is suitable for audio systems, communication, and security systems. It is compliant with UL standards, making it a reliable choice for professional use.

• Type CMP/CL3P (UL), CMP/FT6 (CUL)
• Voltage Rating: 300 V
• Length: 1000 feet

Product Highlights

This cable supports multiple applications including nurse call systems and signaling. Its low smoke PVC insulation ensures safety and compliance.

Product Information

Standard Information

• Application: Audio/Sound System, Communication, Nurse Call, Remote Control, Security System
• Jacket Material: Low Smoke PVC

Technical Specifications

• Conductor Size: 18 AWG
• Number of Conductors: 3
• Insulation Thickness: 0.006 inches
• Jacket Thickness: 0.014 inches
• Outer Diameter: 0.151 inches
• Temperature Rating: -20 to 75 degrees C
• Approval: UL 13, UL 444, CUL
• Wire Length: 1000 FT
