MUELLER INDUSTRIES W1001 Copper Coupling

Product Description

The MUELLER INDUSTRIES W1001 is a straight coupling made from UNS C12200 wrot copper. This coupling features a rolled stop design with female soldered end connections on both sides. It has a size of one-sixteenth inch, making it suitable for ground potable water supply systems and HVAC/R applications. The coupling can handle a pressure rating of 700 PSI at two hundred fifty degrees Fahrenheit. The outer diameter is three-sixteenths inch. It complies with standards set by UL (Canada and US), NSF 61G, ASME B16.15, B16.18, B16.22, B16.24, B16.50, B1.20.1, and MSS SP104. Manufactured in the USA.

• Features female soldered end connections for secure joining.
• Suitable for potable water and HVAC/R systems.
• Complies with multiple industry standards including ASME and MSS.

Product Highlights

Reliable coupling designed for various plumbing and HVAC/R applications.

Product Information

Standard Information

• Brand: MUELLER INDUSTRIES
• MPN: W1001

Technical Specifications

• End Connection: Female Soldered x Female Soldered
• Pressure Rating: 700 PSI at 250 Deg F
• Process: Wrot
• Size A: 1/16 Inch
• Size B: 1/16 Inch
• Temperature Rating: 250 Deg F
• Type: Rolled Stop, Straight
• Material: UNS C12200 Copper
• Outer Diameter: 3/16 Inch
• Application: Ground Potable Water Supply System, HVAC/R
• Applicable Standard: UL (Canada and US), NSF 61G, ASME B16.15/B16.18/B16.22/B16.24/B16.50/B1.20.1, MSS SP104
• Carton Quantity: 100 per Inner Pack, 4000 per Master Pack
