MRCOOL CENTRAL-18-HP-C-230-25 Central Ducted Heat Pump System

Product Description

The MRCOOL CENTRAL-18-HP-C-230-25 is a central ducted heat pump system suitable for both heating and cooling applications. This system includes a condenser and requires an air handler for thorough operation. It uses R-410A refrigerant which is efficient for temperature control. The system supports multi-position installation, making it versatile for various setups. It is AHRI certified, ensuring reliable performance, and features self-diagnostics for troubleshooting error codes. The unit includes a pre-charged line set, simplifying the installation process.

• Cools and heats areas up to 900 square feet.
• Includes a 25-foot pre-charged line set.
• Compatible with multi-position air handlers.

Product Highlights

This system is ideal for residential and light commercial applications where reliable climate control is required.

Product Information

Standard Information

• MPN: CENTRAL-18-HP-C-230-25
• Country of Origin:

Technical Specifications

• Cooling Capacity: 18000 BTU
• Heating Capacity: 18000 BTU
• SEER: 22
• EER: 12.5
• HSPF: 11/9
• Voltage: 208/230 V
• Max Overcurrent Protection: 30 amps
• Minimum Circuit Ampacity: 18
• Refrigerant Type: R410A
• Refrigerant Volume: 56.44 oz
• Decibel Rating High: 39.5
• Decibel Rating Low: 35.5
• Minimum Ambient Cooling: -13F~122F
• Minimum Ambient Heating: -13~75.2F
• Line Set Included: yes
• Line Set Length: 25 ft
• Liquid Line Size: 1/4 in
• Suction Line Size: 1/2 in
• Compressor Motor Type: Rotary
• Condenser Fan Motor RPM: 810/720
• Filter Type: Replaceable
• Auxiliary Heater Available: yes
• Auxiliary Heater Sizes: 5 kw, 8 kw, 10 kw
• Adjustable Thermostat: yes
• Remote Control Included: yes
• AHRI Certified: yes
• Base Warranty: 10 years parts and labor
• Condenser Dimensions: 13.46 in D x 26.50 in H x 35.04 in W
• Condenser Weight: 94.36 lbs
• Air Handler Dimensions: 17.52 in D x 45 in H x 21.02 in W
• Air Handler Weight: 106.48 lbs
• Total Weight: 100.97 lbs
