Mitutoyo 571-200-20 Electronic Depth Gage 0-25mm

Product Description

The MITUTOYO 571-200-20 is a plastic electronic depth gage designed for precise depth measurements in light-duty inspection and machining applications. It measures from 0 to 25mm with a resolution of 0.01mm and an accuracy of 0.0005 inches, making it suitable for quick, repeatable checks on stepped features, slots, and recesses. The 60mm base length provides a stable reference surface across wider workpieces. Powered by a single SR44 battery (included), the gage features auto power off to extend battery life, a low voltage alarm, and a data output port for connecting to statistical process control or data collection systems. Licensed metrologists, machinists, and quality technicians are the typical end users.

This depth gage is suited for dimensional inspection on the shop floor or in a quality control environment. The plastic construction keeps the instrument lightweight and appropriate for use where contact with metal tooling must be minimized. The data output capability allows direct integration with SPC software or compatible Mitutoyo data collection interfaces, reducing transcription error in production inspection workflows. It ships with a battery and storage box included.

Key Features

• Measurement range of 0 to 25mm with 0.01mm resolution
• Accuracy of 0.0005 inches for reliable repeatable readings
• 60mm base length for stable contact across wider reference surfaces
• Data output port for SPC and digital data collection integration
• Auto power off and low voltage alarm to manage battery life
• Includes SR44 battery and storage box ready for immediate use

Compatibility

Designed as an OEM-style electronic depth gage for use in standard dimensional inspection applications requiring a 0 to 25mm measurement range with a 60mm base.

Installation Notes

This instrument requires no installation in the traditional sense but should be handled by qualified metrology or quality control personnel familiar with depth gage operation. Before use, zero the gage on a known flat reference surface with the base seated fully and evenly. Keep the base and blade clean and free of chips or debris to avoid measurement error. Do not expose the unit to coolants or fluids, as the water resistance rating is none.
