Mitutoyo 1160A Back-Plunger Dial Indicator

Product Description

The Mitutoyo 1160A Back-Plunger Dial Indicator is designed for precise measurements in tight spaces. It features a back-plunger design and a back-mounted measuring spindle ideal for use on machine tool tables and inspection jigs.

• Measuring range of zero to five millimeters.
• Graduations of zero point zero one millimeters for accurate readings.
• Includes limit markers and a rotating bezel for ease of use.

Product Highlights

This dial indicator has a hard crystal that resists scratches and glare, enhancing visibility and durability. The outer clamp and optional lifting lever can be mounted on either side without needing tools.

Product Information

Standard Information

• Brand: Mitutoyo
• MPN: 1160A

Technical Specifications

• Measuring Range: 0-5mm
• Graduations: 0.01mm
• Accuracy: +/- 0.016mm
• Range/Rev: 1mm
• Dial Reading: 0-100
• Measuring Force: 0.4 - 1.4N
• ISO/JIS Type: 8mm Stem with M2.5 x 0.45 Thread
• Supported Measurement Unit(s): mm
