Mitsubishi Multi-Zone 40500 BTU R-454B 16 SEER2 4-Zone Ducted Low-Static Mini Split Heat Pump System - 9K+12K+12K+12K

Description

This comprehensive HVAC bundle features the Mitsubishi Electric MXZ-5D42NL outdoor condenser paired with three concealed duct indoor units (SEZ-AD09NL and SEZ-AD12NL) for optimal heating and cooling across multiple zones. The outdoor unit delivers a robust 42,000 BTU cooling capacity and can connect up to five indoor units, making it ideal for both residential and light commercial applications. The indoor units are designed for discreet installation, providing efficient climate control without compromising aesthetics. This bundle is perfect for those seeking a versatile and energy-efficient solution to meet their heating and cooling needs.

What's Included

• MITSUBISHI ELECTRIC MXZ-5D42NL - Mitsubishi Electric MXZ-5D42NL 42k BTU (3.5 Ton) M-Series Outdoor Condenser up to 5 Zones (Qty x1)
• MITSUBISHI ELECTRIC SEZ-AD09NL - Mitsubishi Electric SEZ-AD09NL 9k BTU (0.75 Ton) 208/230V M-Series Concealed Duct AHU (R-454B) (Qty x1)
• MITSUBISHI ELECTRIC SEZ-AD12NL - Mitsubishi Electric SEZ-AD12NL 12k BTU (1.00 Ton) 208/230V M-Series Concealed Duct AHU (R-454B) (Qty x3)

Key Details

• Weight of Bundle: 381 lb (Mitsubishi 194 lb + Mitsubishi 40 lb + Mitsubishi 147 lb)
• Cooling BTU: 42,000
• Heating BTU: 53,600
• Indoor Unit Sizes: 9, 12 (x3)
• SEER2: 19.3
• Voltage: 208/230V
• Refrigerant Type: R-454B
• Sound Level: 30 dB (min) to 59 dB (max)
• Dimensions (Outdoor Unit): 31.43" H x 37.45" W x 13" D
• Dimensions (Indoor Units): 7 7/8" H x 31 1/8" W x 27 9/16" D (9k BTU), 7 7/8" H x 39" W x 27 9/16" D (12k BTU)

Use & Compatibility

This bundle is designed for multi-zone heating and cooling applications, making it suitable for both residential and light commercial spaces. The outdoor condenser is compatible with up to five indoor units, allowing for tailored climate control in various settings. Ideal for installation in attics, ceilings, or wall structures, the concealed duct indoor units provide efficient performance while maintaining a low profile.
