MISCELLANEOUS PRODUCT C2004N-1B1-DX

Product Description

The MISCELLANEOUS PRODUCT C2004N-1B1-DX is a single-stage compressed air filter designed to remove contaminants effectively.

• Achieves up to 99.99% efficiency for particles and droplets as small as 0.01 microns.
• Constructed with anodized aluminum and nylon, ensuring durability.
• Designed for continuous liquid removal without sacrificing efficiency.

Product Highlights

This filter is suitable for high-performance applications, protecting equipment and instruments from compressed air impurities.

Product Information

Standard Information

• Brand: Balston
• MPN: C2004N-1B1-DX

Technical Specifications

• Product Type: Single Stage Filter
• Port Size: 1/2 inch
• Port Type: NPT
• Micron Rating: 0.01 micron
• Maximum Operating Pressure: 250 psig, 17.2 barg
• Maximum Flow Rate: 63 CFM, 107.03 m3/min
• Maximum Operating Temperature: 129 °F, 54 °C
• Minimum Operating Temperature: -150 °F, -100 °C
• Drain Port Size: 1/8 inch
• Connection Type: NPT
• Efficiency: 93 %
