Product Description
The Minuteman ETR1500LGU Entrust-LG series is a line-interactive mini tower UPS, suitable for small to medium-load applications. It provides protection against power fluctuations and outages. It supports a wide range of equipment, including computers, DVRs, network devices and telephone systems. The UPS features automatic voltage regulation and a compact mini-tower design.
- Offers 1500 VA load capacity for sufficient backup during power failures.
- Features 5 battery and surge-protected outlets and 5 surge-only outlets.
- Includes USB Type-A and Type-C charging ports.
Product Highlights
The Minuteman ETR1500LGU UPS provides reliable power protection with automatic voltage regulation, multiple outlets, and a compact design for seamless integration into various environments.
Product Information
Standard Information
-
Brand: Minuteman
-
Manufacturer Part Number: ETR1500LGU
-
Country of Origin: Vietnam
Technical Specifications
-
Brand Name: Minuteman
-
Manufacturer: Para Systems, Inc
-
Product Line: Entrust-LG
-
Product Model: ETR1500LGU
-
Product Type: UPS
-
ADI Part Number: R1-ETR1500LG
-
Application/Usage: AV Cabinet,CCTV Camera,Computer,Desktop,DVR,Gaming Console,Network Equipment,Security Closet,Telephone System,VoIP,Workstation
-
Form Factor: Mini-tower
-
Load Capacity (VA): 1500 VA
-
Load Capacity (W): 900 W
-
Input Voltage: 120V AC
-
Output Voltage: 104V AC,120V AC,140V AC
-
Input Frequency: 60 Hz
-
Waveform Type: Step Simulated Sine Wave
-
Receptacle Type: NEMA 5-15R,USB Type A,USB Type C
-
Receptacle Detail: 1 x USB Type A,1 x USB Type C,10 x NEMA 5-15R
-
Plug/Connector Type: NEMA 5-15P
-
Dataline Protection: Coax,RJ-45
-
Replaceable Battery: Yes
-
USB (HID Compliant) Port: Yes
-
Energy Star: Yes
-
Environmental Certification: Energy Star 2.0,RoHS 2
-
Environmentally Friendly: Yes
-
AVR: Yes
-
Network (RJ-45): yes
-
Number of Battery & Surge Outlets: 5
-
Number of Surge-only Outlets: 5
-
Maximum Operating Temperature: 104°F (40°C)
-
Maximum Operating Elevation: 10000 ft
-
Input Voltage Range: 90 V AC - 140 V AC
-
Input Frequency (Hz): 60.000
-
Remote Management Interface: USB
-
Interface Provided: 1 x management (USB), 1 x USB-A, 1 x USB-C
-
Emergency Power Off: Audible alarm, Automatic self-test, Automatic Voltage Regulation (AVR), Hot-swappable batteries, Latching, LCD display, Overcurrent protection, Short-circuit protection
-
Frequency Provided: 60 hertz
-
Input Connector Type: Power NEMA 5-15
-
Load Type: At full load
-
Max Run Time: 12.6 min at half load, 3.5 min at full load
-
Max Spike Current: 10 ampere
-
Output Connector Quantity: 10
-
Power Provided: 900 watt
-
Provided Voltage: AC 104-140 volt
-
Required Voltage: AC 90-140 volt
-
Surge Suppression: Yes
-
Switching Capacity: 6 millisecond
-
UPS Technology: Line interactive
-
Voltage Provided Margin: ± 6%
-
Battery Run Time (Up To): 3.5 minute (time unit)
-
Form Factor (Power Device): External
-
Min Operating Temperature: 32 degree Fahrenheit
-
Operating Humidity: 0 - 95% (non-condensing)
-
Packaged Quantity: 1
-
Subcategory: UPS
-
Depth: 16.1 inch
-
Color Category: Black
-
Compliant Standards: cTUVus, FCC Class B certified, RoHS 2
-
ENERGY STAR Certified: No
-
EPEAT Compliant: No
-
TCO Certified: No
-
Surge Energy Rating: 1330 joules
-
Watts: 900W
-
Outlets: 10
-
Outlet Type: NEMA (5) 5-15R Surge Only
NEMA (5) 5-15R Battery & Surge
-
Battery Replaceable: BM0066
-
Alarms: Battery Function Alarms
-
Alarm Silencer: Alarm Silencer
-
Interface Port: (1) Type A & (1) Type C
-
Approvals: cTUVus (Conforms to UL1778 5th Edition & CSA 22.2 no. 107.3:2014/R:2017-10) 3rd Edition, FCC 47 CFR Part 15, Subpart B: 2020, CE certified, Energy Star2.0
-
Protection: Circuit Breaker
-
Temperature: +32°F to +104°F (0°C to +40°C)
-
Humidity: 0% to 95% (Non-condensing)
-
Battery Cell Composition: Lead Acid
-
Material: Plastic
