Milwaukee MDP8D-2000 8D Collated Duplex Nails 2-pack

Product Description

The Milwaukee MDP8D-2000 is a 2-pack of 8D collated duplex nails designed for pneumatic nailers used in formwork, temporary bracing, and double-headed nailing applications. Each nail measures 2.25 inches in length with a 0.131-inch shank diameter. The duplex head design allows for easy removal after temporary structures are dismantled, making these nails a standard choice for concrete forming, scaffolding, and staging work. These are sold as an each unit, with two boxes included per purchase. Carpenters, concrete form crews, and general contractors are the primary installers.

These collated duplex nails are suited for residential and commercial construction applications where temporary fastening is required. Typical use cases include concrete formwork panels, temporary shoring, and scaffold decking where the nails must be driven fully but pulled cleanly after the pour or work is complete. The double-head shank design gives a solid drive while leaving the upper head exposed for easy pry-bar removal. These nails are compatible with pneumatic nailers that accept 8D collated framing nails in the appropriate collation angle.

Key Features

• 8D duplex double-head design allows clean removal from temporary structures
• 2.25-inch length with 0.131-inch shank diameter for secure temporary fastening
• Collated format compatible with pneumatic nailers accepting 8D collated nails
• Sold as a 2-pack for extended use on larger forming or staging jobs
• Designed for formwork, bracing, and other temporary construction applications

Compatibility

Designed for use with pneumatic nailers that accept 8D collated duplex nails. Verify collation angle and nail diameter specifications on the nailer before use.

Installation Notes

Installation is typically performed by carpenters or concrete form crews using a compatible pneumatic framing nailer. Confirm the nailer magazine accepts the collation style and shank diameter of these nails before loading. When removing nails after formwork is stripped, use a flat pry bar under the upper duplex head to avoid splitting lumber where reuse is intended. Follow applicable jobsite safety requirements for pneumatic fastening tools.

Technical Specifications

• Nail Size: 8D
• Nail Length: 2.25 inches
• Shank Diameter: 0.131 inches
• Nail Type: Collated Duplex
• Package Quantity: 2
• Unit of Measure: EA
• Weight: 54.19 pounds

Standard Information

• Brand: Milwaukee Electric Tool Corp
• Manufacturer Part Number: MDP8D-2000
