Milwaukee 96270 Mechanical Marking Holder

Product Description

The MILWAUKEE 96270 is a refillable mechanical marking holder designed for trade professionals who need to mark in confined, hard-to-reach spaces. Its extended needle-nose tip reaches through holes and into tight areas where standard markers and pencils cannot. The all-metal body is built for heavy-duty jobsite use, and the one-click advance mechanism delivers a controlled amount of lead with each press. A built-in sharpener maintains a precise tip for clean, accurate marks. At 0.28 pounds, the holder is lightweight without sacrificing durability. It ships with one graphite lead installed and is sized for 2.8 mm diameter by 120 mm length refills.

This holder is suited for use in welding fabrication, plumbing rough-in, HVAC sheet metal work, electrical layout, and general construction applications where marking in tight clearances is a regular requirement. The needle-nose tip is especially useful when marking through knockout holes, inside conduit knockouts, or along confined structural members. The refillable design reduces waste and keeps the tool in service long-term without replacement of the entire holder.

Key Features

• Extended needle-nose tip reaches through holes and into tight, confined areas
• All-metal construction rated for heavy-duty jobsite conditions
• One-click lead advance delivers a controlled, consistent amount of lead
• Built-in sharpener maintains a precise marking tip
• Refillable design accepts Markal Pro 2.8 mm diameter by 120 mm length refills
• Includes one graphite lead installed at the factory

Compatibility

Compatible with all Markal Pro Welding Pro General-Purpose Refills in 2.8 mm diameter by 120 mm length. Use only Markal Pro-specification refills to ensure proper fit and advance function.

Installation Notes

No tools or power source are required for operation or lead replacement. To refill, remove the tip assembly, insert a replacement Markal Pro 2.8 mm refill, and reassemble before advancing. Use the built-in sharpener to dress the lead tip before marking on irregular or rough surfaces. Keep the tip retracted when the holder is stored to prevent breakage.

Technical Specifications

• Weight: 0.28 pounds
• Lead Diameter: 2.8 mm
• Lead Length: 120 mm
• Body Material: Metal
• UPC: 048615962702
• Unit of Measure: Each

Standard Information

• Brand: MILWAUKEE
• Manufacturer Part Number: 96270
