Milwaukee 49-57-1625 Steel Hawg Annular Cutter 1-5/8 in

Product Description

The MILWAUKEE 49-57-1625 is a threaded Steel Hawg annular cutter designed for fast, clean hole cutting in metal. It features carbide teeth in an alternating cutting pattern that delivers cutting speeds up to three times faster than standard twist drill bits. The cutter handles hole depths up to 2 inches in steel, stainless steel, cast iron, and aluminum. A spring-loaded, self-ejecting pilot pin serves as both a centering pin and a plug ejector, improving cut accuracy and speeding up workflow. This cutter is built for use with electromagnetic and magnetic drill presses. It ships as a single unit and weighs 0.51 pounds.

The 49-57-1625 is suited for metal fabrication, structural steel work, mechanical contractors, and electricians drilling through steel studs, angle iron, or plate. It is designed for use with most electromagnetic drill presses in commercial and industrial settings. The cutter is compatible with Milwaukee magnetic drill press model 4262-1 using arbor 49-57-0030, and with Milwaukee model 4292-1 using arbor 49-57-0010. It is also compatible with a No. 3 Morse taper arbor assembly 49-57-0010. The 1-5/8 inch bit diameter uses an M18 x 1.5 metric thread shank.

Key Features

• Alternating tooth form geometry cuts up to 3 times faster than twist drill bits
• Abrasion-resistant carbide teeth extend cutter life and produce a cleaner hole edge
• Spring-loaded self-ejecting pilot pin doubles as a centering pin for accurate starts
• Cuts up to 2 inches deep in steel, stainless steel, cast iron, and aluminum
• M18 x 1.5 threaded shank fits most electromagnetic drill press arbors

Compatibility

Compatible with Milwaukee magnetic drill press model 4262-1 using arbor 49-57-0030, Milwaukee model 4292-1 using arbor 49-57-0010, and any electromagnetic drill press accepting a No. 3 Morse taper arbor assembly 49-57-0010.

Installation Notes

Installation and use of this cutter should be performed by a qualified tradesperson familiar with electromagnetic drill press operation. Before mounting or changing cutters, disconnect or power down the drill press completely. Secure the workpiece firmly before cutting to prevent movement during operation. Always use the correct arbor for the specific drill press model to ensure proper seating and safe operation.

Technical Specifications

• Cutting Diameter: 1-5/8 inches
• Maximum Cut Depth: 2 inches
• Thread Size: M18 x 1.5
• Compatible Materials: Steel, Stainless Steel, Cast Iron, Aluminum
• Tooth Type: Carbide, Alternating Tooth Form
• Weight: 0.51 pounds
• Length: 2.5 inches
• Width: 3.7 inches
• Height: 2.3 inches
• UPC: 0045242202256

Standard Information

• Brand: MILWAUKEE
• Manufacturer Part Number: 49-57-1625
