Milbank U3000-O-K3L-K2L-ALT Single Position Meter Socket 320 Amp 600V

Product Description

The Milbank U3000-O-K3L-K2L-ALT is a single position meter socket designed for effective power distribution. It operates with a 320 amp capacity and is rated for 600 volts. This ringless socket features a lever bypass and four terminals, intended for underground applications.

• Amperage rating of 320 amps
• Compatible for underground installations
• UL listed and rated Type 3R, ensuring durability

Product Highlights

This meter socket is suitable for both residential and commercial use. It provides a reliable connection for metering devices while maintaining safety standards.

Product Information

Standard Information

• Brand: Milbank
• MPN: U3000-O-K3L-K2L-ALT

Technical Specifications

• Catalog Number: U3000-O-K3L-K2L-ALT
• Manufacturer: Milbank
• Country of Origin: United States
• Application: Meter Socket
• Bypass Type: Lever
• Cable Entry: Underground
• Enclosure: G90 Galvanized Steel with Powder Coat Finish
• Voltage Rating: 600 Volts Alternating Current
• Frequency Rating: 60 Hertz
• Material: G90 Galvanized Steel
• Mounting: Surface Mount
• Number of Jaws: 4 Terminal
• Phase: 1
