Micro 100 50-1100 Turning Insert Ccmt 21.51 Solid Carbide

Product Description

The MICRO 100 50-1100 is a solid carbide turning insert in the CCMT 21.51 style, designed for precision metal cutting in CNC and manual lathe applications. It features a diamond 80-degree insert shape with a neutral hand orientation and a 0.0157-inch corner radius. The insert delivers positive rake geometry with a flat-top chip breaker and a honed cutting edge, supporting clean chip formation and controlled surface finish. Two cutting edges are available per insert. This insert is installed by machinists and CNC operators working in production turning, facing, chamfering, and boring operations.

The 50-1100 is suited for light to medium turning work where a positive-rake, screw-held CCMT insert is specified. It fits standard CCMT-style toolholders designed for the 21.51 insert size, with an inscribed circle of 0.2500 inches and an insert thickness of 0.0938 inches. Typical applications include external turning, internal boring, facing passes, and chamfering on a range of ferrous and non-ferrous workpiece materials. The flat-top chip breaker geometry is well matched to light finishing and semi-finishing cuts with a maximum depth of cut of 0.0852 inches.

Key Features

• Solid carbide construction for hardness and wear resistance in turning operations
• CCMT 21.51 insert style with diamond 80-degree included angle and neutral hand
• Positive rake geometry with flat-top chip breaker for efficient chip control
• Honed cutting edge for improved edge stability and surface finish
• Two usable cutting edges per insert for extended tooling value
• Screw-held mounting compatible with standard CCMT toolholder pockets
• Multi-use application: turning, facing, chamfering, and boring

Compatibility

Designed as an OEM-style replacement or direct-fit insert for standard CCMT-style toolholders accepting the 21.51 insert size with a 0.2500-inch inscribed circle.

Installation Notes

Installation is performed by a machinist or CNC tooling technician. Power down and lock out the machine spindle before seating or indexing the insert. Use the appropriate torx or hex key to secure the clamping screw to the toolholder manufacturer's specified feel - do not overtighten, as carbide inserts are brittle and can crack under excess clamping force. Verify insert seating and edge orientation before resuming cuts.
