Mersen MPDBE6263 End Barrier Snap-On to Adder Pole Miniature Power Distribution Blocks

Brand: MERSEN
SKU: MPDBE6263
Availability: In Stock

Ships same day if ordered by 12 pm
$21.60
$21.60
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The MERSEN MPDBE6263 is an end barrier for power distribution blocks, providing a safe and easy method for splicing cables and splitting primary power into secondary circuits. It meets requirements for fixed junction tap-off points and is UL and CSA approved. It is suitable for feeder and branch circuits in conjunction with UL508A and the National Electrical Code.

  • Optional adder poles for increased flexibility and ease-of-use
  • Made of glass-filled polycarbonate
  • Suitable for miniature MPDB62 and MPDB63 series

Product Highlights

The MERSEN MPDBE6263 end barrier offers a reliable solution for power distribution, ensuring safety and flexibility in various electrical applications.

Product Information

Standard Information

  • Brand: MERSEN
  • Manufacturer Part Number: MPDBE6263
  • Country of Origin: Mexico
Technical Specifications
Item number
MPDBE6263
Description
Open-Style PDB UL 1953 1000V Mini End Barrier
EAN/UPC Code
782001449360
Rated voltage AC UL
1000 V
Rated voltage DC UL
1000 V
Frequency (Hz)
50/60 Hz
ROHS Compliant
Yes
AC or DC
AC/DC
Short Circuit Rating (Standalone)
10 kA
Product Width
16.5 mm
Product Length
144.8 mm
Product Height
26.7 mm
Product group
Parts for multipole assembly
Brand
MERSEN
Model
MERSEN MPDBE6263
Country of Origin
China
UNSPSC Code
39120000
Manufacturer Part Number
MPDBE6263
Number of Poles
Adder
Primary Type
Power Distribution Block
Series
MPDB Series
Voltage Rating
1000 V
Compatible with Series
63; 66; 67; 68; 69; MPDB62
Material
Polycarbonate
Mounting Type
Clip-On
Mount
Clip-On
Overall Depth
26.7 mm
Overall Length
144.8 mm
Overall Width
16.5 mm
Standards
CSA; National Electrical Code ; RoHS; UL; UL 1953; UL508A
Thickness
0.075 in
