Mersen MPDB69313 3-phase Power Distribution Block

Product Description

The MERSEN MPDB69313 is a 3-phase power distribution block designed to split and distribute electrical power from a single input to multiple output circuits within a panel or enclosure. Distribution blocks of this type provide a reliable, code-compliant termination point for branch circuit wiring, reducing reliance on wire nuts or bus bars in high-current commercial and industrial installations. This unit is sold in a pack of 2. Licensed electricians and panel shop technicians are the primary installers of this component.

This distribution block is suited for 3-phase electrical distribution applications in commercial and industrial environments. It is commonly installed in motor control centers, main distribution panels, sub-panels, and custom electrical enclosures where organized multi-circuit power distribution is required. The physical footprint measures 5.690 inches by 4.000 inches by 17.750 inches, making it compatible with standard deep enclosure installations.

Key Features

• 3-phase configuration supports multi-circuit branch distribution from a single input
• Sold as a 2-pack, reducing per-unit cost on larger installations
• Compact footprint at 5.690 x 4.000 x 17.750 inches fits standard panel enclosures
• UPC-verified unit: 78200145264

Compatibility

Designed as an OEM-style replacement or new-installation component for 3-phase power distribution applications in commercial and industrial electrical enclosures and panelboards.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize and lock out the panel or enclosure before beginning any work. Verify that conductor sizing and torque specifications match the block ratings per manufacturer documentation before terminating wires. Do not exceed the rated conductor fill for any input or output port.

Technical Specifications

• Phase Configuration: 3-Phase
• Dimensions (L x W x H): 5.690 inches x 4.000 inches x 17.750 inches
• Weight: 5.4 pounds
• Pack Quantity: 2 per pack
• UPC: 78200145264

Standard Information

• Brand: MERSEN
• Manufacturer Part Number: MPDB69313
