Mersen MPDB67582 Power Distribution Block 175A 2 Pole

Product Description

The Mersen MPDB67582 Power Distribution Block is designed for securely splitting primary power into secondary circuits and ensures reliable connection within industrial settings. Crafted from tin-plated aluminum, this block supports a two-pole configuration and is capable of handling up to 175 amps with a voltage rating of 1000V.

• UL 1953 listed and CSA certified for safety and reliability.
• Easy installation with screw mounting and open-style architecture.
• Supports adder poles for enhanced flexibility and custom wire combinations.

Product Highlights

This robust unit features optional polycarbonate safety covers for extra protection and shock resistance, meeting stringent industry standards for feeder and branch circuit applications.

Product Information

Standard Information

• Brand: Mersen
• Item Type: Open-Style Power Distribution Blocks

Technical Specifications

• Mounting Style: Screw
• Material: Tin-plated Aluminum
• Connection Type: Box to Box
• Voltage Rating: 1000V
• Amperage Capacity: 175A
• Number of Poles: 2
• Country of Origin: Mexico
• Special Features: Adder Poles, Optional Safety Covers
