Mersen MPDB66512 Intermediate Open Style Power Distribution Block 600 VAC 350 A 2 Poles

Product Description

The Mersen MPDB66512 is an intermediate open style power distribution block designed to simplify electrical connections. This block operates at a voltage of six hundred VAC and has a current rating of three hundred fifty amps. It provides two poles and accommodates wire sizes from fourteen to two/0 AWG. The block's construction includes durable polycarbonate material, suitable for various applications in electrical distribution systems.

• Safe and easy cable splicing
• Dual conductor primary inputs with multiple secondary outputs
• UL and CSA approved for compliance with industry standards

Product Highlights

Designed for cable splicing, this power distribution block allows for efficient splitting of primary power into secondary circuits, providing fixed junction tap-off points.

Product Information

Standard Information

• Brand: Mersen
• Manufacturer: Mersen

Technical Specifications

• Catalog Number: MPDB66512
• Voltage Rating: 600 VAC
• Amperage Rating: 350 A
• Number of Poles: 2
• Primary Connections/Pole: 2
• Secondary Connections/Pole: 6
• Wire Size: 14 to 2/0 AWG
• Short Circuit Current Rating: 100 kA
• Dimensions: 3.25 in H x 3.57 in W x 5 in D
• Material: Polycarbonate
• Country of Origin: Mexico
