Mersen 6633J Fuse Block Class J 600A 3-Pole

Product Description

The MERSEN 6633J is a fuse block designed for circuit protection. It supports 600A and is rated for both 600VAC and 600VDC. This Class J fuse block features a 3-pole configuration with box in-line clip connectors, suitable for a range of stranded or solid copper or aluminum conductors. Insulators are made from molded glass-filled polycarbonate or phenolic.

• Rated for 600VAC and 600VDC
• Features a 3-pole configuration
• Equipped with box in-line clip connectors

Product Highlights

Class J fuse block with a 3-pole configuration and box in-line clip connectors, designed for circuit protection.

Product Information

Standard Information

• Brand: MERSEN
• Manufacturer Part Number: 6633J

Technical Specifications

• Item number: 6633J
• Description: Fuse Block 600VAC 600VDC Class J 600A 3-Pole Box In-Line Clip
• Rated voltage AC UL: 600 V
• Rated voltage DC UL: 600 V
• Frequency (Hz): 50/60 Hz
• Ampere Rating: 600 A
• ROHS Compliant: Yes
• AC or DC: AC/DC
• Fuse Class: Class J
• Short Circuit Current Rating (SCCR): 200 kA
• Number of Poles: 3-Pole
• Fuse Installation Method: Clip-in
• Max Fuse Rating: 600 A
• Installation Mounting: Direct Screw Mount
• Product Width: 12 in
• Product Length: 11 in
• Product Height: 4.74 in
• Body/Insulating Material: Phenolic
• Current Rating: 600 A
• Voltage Rating: 600 V
• Manufacturer Part Number: 6633J
• Primary Type: Fuse Holder
• Type: Fuse holder
• Number of Circuits: 3
• Mounting Type: Chassis Mount
• Orientation: Horizontal
• Termination Style: Box Lug
• For Use With/Related Products: Class J Fuses
• Brand / Manufacturer: MERSEN (FERRAZ SHAWMUT)
• Voltage: 600
• Series: 6633
• Catalog Number: 6633J
• Catalog / Class: Fuse Block
• SKU: 6633J
