Merit Brass ADI-160 Back-Up Flange 10 in Replacement MPN

Product Description

Merit Brass Back-Up Flange with MPN ADI-160 is designed for industrial applications. This product features a nominal size of ten inches. The inside diameter measures ten and seven-eighths inches. It has a thickness of five-eighths inches, ensuring durability and strength. The bolt circle diameter is fourteen and one-fourth inches, accommodating twelve bolt holes for secure installation.

• Nominal size: 10 inches
• Material: Ductile iron
• Includes twelve bolt holes

Product Highlights

This Merit Brass flange is built for effective connections in piping systems. It is suitable for various industrial applications, ensuring reliability and ease of use.

Product Information

Standard Information

• Brand: Merit Brass
• MPN: ADI-160

Technical Specifications

• Nominal Size: 10 in
• Inside Diameter: 10-7/8 in
• Outside Diameter: 16 in
• Thickness: 5/8 in
• Bolt Circle Diameter: 14-1/4 in
• Bolt Hole Size: 1 in
• Number of Bolt Holes: 12
• Material: Ductile Iron
• Domestic/Import: Import
