Merit Brass ADI-16 Back-Up Flange Power 1 in Replacement MPN

Product Description

The Merit Brass ADI-16 is a back-up flange made from ductile iron. It has a nominal size of one inch and an inside diameter of one point three eight inches. This product features a bolt circle diameter of three and one eighth inches and includes four bolt holes for secure attachment. The thickness of the flange is one half inch.

• Material: Ductile Iron
• Nominal Size: 1 in
• Inside Diameter: 1.38 in

Product Highlights

This flange is suitable for various piping systems and is reliable for connections that require a robust backing. The design allows for easy installation with its standard bolt hole layout.

Product Information

Standard Information

• Brand: Merit Brass
• Manufacturer: Merit Brass

Technical Specifications

• Nominal Size: 1 in
• Inside Diameter: 1.38 in
• Outside Diameter: 4-1/4 in
• Thickness: 1/2 in
• Bolt Circle Diameter: 3-1/8 in
• Bolt Hole Size: 0.622 in
• Number of Bolt Holes: 4
• Domestic/Import: Import
