Mencom CKF-03 Female Rectangular Insert 10 Amp (21.21)

Product Description

The Mencom CKF-03 is a CK series female rectangular insert (part CKF-03) with a 4-pin configuration rated 10 A and screw termination. The insert is sized for a 21.21 footprint, rated to 600 V, and uses silver-plated contacts in a self-extinguishing thermoplastic body. The UL working temperature range is -40 to +125 °C. Typical use includes mating assemblies with ILME-compatible hoods and bases for industrial connector applications.

• 4-pin female rectangular insert, 10 A amperage rating and 600 V voltage rating with screw termination
• Silver-plated contacts in self-extinguishing thermoplastic housing; UL temperature range -40 to +125 °C
• Enclosure/insert dimension 21.21; compatible with CK series hoods and bases for rectangular connector assemblies

Product Highlights

4-pin female insert, 10 A/600 V, screw termination, size 21.21, silver contacts

Product Information

Standard Information

• Brand: MENCOM
• Manufacturer Part Number: CKF-03
• Country of Origin: Italy

Technical Specifications

• Brand: Mencom
• Part Number: CKF-03
• Series: CK
• Component Type: Female rectangular insert
• Insert Type: Standard
• Pin Count: 4
• Contact Configuration: 4 (3+E)
• Amperage Rating: 10 A
• Voltage Rating: 600 V
• Termination: Screw
• Contact Plating: Silver
• Material: Self-extinguishing thermoplastic
• Temperature Range: -40 to +125 °C
• Enclosure Dimension: 21.21 (series size)
• Gender: Female
• Upper AWG: 14
• Lower AWG: 18
• RoHS: Yes
• Country of Origin: IT (Italy)
