McDonnell & Miller 153927 PSE-802-24 Low Water Cut-Off 24V

Product Description

The McDonnell & Miller 153927 PSE-802-24 is a 24-volt electronic low water cut-off device designed for steam boilers. This unit features a self-cleaning probe that requires maintenance once every five years. It also includes a manual reset and has an LED indicator for power and low water conditions.

• Automatic reset function
• Green LED for power indication
• Red LED for low water warning

Product Highlights

This low water cut-off control is suitable for both steam and hot water heating boilers, making it versatile for various applications.

Product Information

Standard Information

• Brand: McDonnell & Miller
• Manufacturer: Xylem

Technical Specifications

• Model: PSE-802-24
• Type: Electronic
• Voltage Rating: 24 VAC
• Pressure Rating: 15 psi Steam, 160 psi Water
• Temperature Rating: -40 to 120 degrees Fahrenheit Storage, 32 to 120 degrees Fahrenheit Ambient, 250 degrees Fahrenheit Water
• Dimensions: 2-7/8 inches L x 4-1/4 inches W x 5-13/16 inches H
• VA Rating: 50 VA
• Applications: For steam boilers
