Master Lock 1175 Combination Lock Resettable Dial

Product Description

The MASTER LOCK 1175 is a dial-combination padlock built for demanding commercial and industrial environments. The body measures 2 inches high and 2-1/4 inches wide, housing a resettable dial mechanism that eliminates the need for keys. The shackle is made from boron carbide, one of the hardest materials used in lock construction, offering strong resistance to cutting and sawing. The shackle diameter is 3/8 inches with a 15/16-inch shackle width and 1-1/16-inch shackle clearance. Licensed electricians, utility technicians, maintenance crews, and security personnel are the primary installers and users of this lock.

The MASTER LOCK 1175 is rated for use across a wide range of commercial and industrial applications including cable boxes, construction sites, equipment lockout, industrial and storefront gates, manufacturing environments, electrical substations, and utility meters. Its resettable combination makes it a practical choice for facilities requiring periodic access code changes without rekeying. It is suitable for both indoor and outdoor use where a durable, keyless security solution is needed.

Key Features

• Resettable dial combination — no keys required, access code can be changed in the field
• Boron carbide shackle for high resistance to cutting and sawing
• Shackle diameter of 3/8 inches fits standard hasps and cable box hardware
• 1-1/16-inch shackle clearance accommodates a variety of hasp thicknesses
• Compact 2-inch body height suits space-constrained applications
• Rated for cable boxes, substations, construction sites, and manufacturing environments

Compatibility

Designed for use with cable boxes, construction site equipment, industrial and storefront gates, manufacturing environments, electrical substations, and utility meters where a dial-combination padlock with a resettable code is required.

Installation Notes

Installation is performed by electricians, utility technicians, or facilities maintenance personnel following applicable lockout/tagout (LOTO) procedures per OSHA 29 CFR 1910.147. Before applying this lock in a lockout/tagout application, verify that the hasp or mounting point is rated for the shackle diameter. To reset the combination, follow the manufacturer reset procedure with the shackle in the open position. Do not force the shackle closed before the combination is fully confirmed.
