MASKA MBL82 Fixed Pitch Sheave

Product Description

The MASKA MBL82 is a fixed pitch sheave suitable for A or B belts. It is built for light-duty applications with a groove bushing type that provides reliable operation. The outer diameter measures eight point two inches and it requires an LX type bushing for installation.

• Designed for A or B belts
• Groove bushing type for proper fit
• Constructed from durable cast iron

Product Highlights

This sheave is made for compatibility with A and B belts, ensuring flexibility for various applications.

Product Information

Standard Information

• Manufacturer Part Number: MBL82
• Type: Fixed Pitch Sheave

Technical Specifications

• Compatible Belt Types: A or B (requires LX type bushing)
• Outer Diameter: 8.2 inches
• Weight: 4.65 lbs
• Sheave Type: Light Duty Type 5A
• Bore Size: 1/2 to 1-1/2 inches
• Pitch Diameter: 7.85 inches (A/4L), 8.25 inches (B/5L)
• Face Width: 29/32 inches
• Bushing: MBL Bushing
• Overall Length: 1.438 inches
• V-Belt Cross Section: A-B, 4L, 5L
• Material: Cast Iron
• Item Weight: 4.65 lbs
