Martin R6X4 Steel Gear Rack - 6 DP, 14.5 Degrees Pressure Angle, 1.5 in Width, 4 ft Long

Product Description

The Martin R6X4 Steel Gear Rack is made from low carbon cold drawn steel. It features a diametral pitch of six and a pressure angle of 14.5 degrees. This gear rack comes in a length of four feet and has a face width of one and a half inches. It allows for cutting and machining adjustments. Pinions for operation can be chosen from the spur gear catalog. Custom gear racks can be supplied in different materials, sizes, and pitches.

• Diameter pitch of six
• Pressure angle of 14.5 degrees
• Custom sizes and materials available

Product Highlights

The Martin R6X4 is ideal for various mechanical applications where precise gear movement is crucial.

Product Information

Standard Information

• Brand: Martin
• Part Number: R6X4

Technical Specifications

• Face Width: 1.5 in
• Pressure Angle: 14.5 degrees
• Overall Thickness: 1 in
• Length: 4 ft
• Material: Steel
• Weight: 16.88 LB
• Diametral Pitch: 6
• EAN: 697950059198
