Martin 9CH3264 Screw Conveyor Hangers

Brand: MARTIN
SKU: 9CH3264
Availability: Out Of Stock
$211.83
$211.83
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The Martin 9CH3264 Screw Conveyor Hangers are built to support screw conveyor systems. These hangers minimize disruption to material flow by accommodating expansions, especially in high-heat environments.

  • Designed for 9 inch conveyor diameter
  • Features a 2 inch coupling diameter
  • Constructed with robust materials for durability

Product Highlights

These hangers are essential in applications requiring effective support and minimal obstruction.

Product Information

Standard Information

  • Brand: Martin
  • Part Number: 100847684

Technical Specifications

  • Bolt Hole Width: 10 inches
  • Hanger Type: 326
  • Conveyor Diameter: 9 inches
  • Mounting Distance (Drop): 6 1/8 inches
  • Coupling O.D.: 2 inches
  • Oil Pipe: No
  • Bolt Hole Length: 4 1/2 inches
  • Weight: 11.0 pounds
  • EAN or UPC: 697950125077
