Martin 60BS1811/4 Bored-to-Size Sprocket

Product Description

The Martin sprocket model 60BS1811/4 is a bored-to-size type BS single pitch roller chain sprocket. It features a bore diameter of one and one-quarter inches and an outside diameter of four point seven zero three inches. This sprocket is designed for use with #60 chain and has eighteen teeth. The pitch of the sprocket is three-fourths inch. Constructed of steel, it includes keyways and two set screws for easy installation.

• Ideal for various power transmission applications.
• Finished bores ensure readiness for immediate use.
• Keyways positioned on the centerline of the teeth.

Product Highlights

This sprocket is is suitable for use in industries requiring reliable chain drive systems.

Product Information

Standard Information

• Brand: Martin Sprocket & Gear
• Part Number: 60BS1811/4

Technical Specifications

• Bore Diameter: 1-1/4 in
• Chain Size: #60
• Hub Diameter: 3 in
• Includes: (2) Setscrews
• Keyway Size: 1/4 x 1/8 in
• Length Through Bore: 1-1/4 in
• Material: Steel
• Number of Teeth: 18
• Pitch: 3/4 in
• Pitch Diameter: 4.319 in
• Screw Size: 5/16-18 x 5/16 in
• Standards/Approvals: PROP65 warning applies. For details, refer to www.P65Warnings.ca.gov
• Type: Bored-to-Size Type BS
