Martin 50BTB24H MSG Saber Tooth Single Pitch Roller Chain Sprocket With Hardened Teeth 5.122 In OD #50 Chain 24 Teeth

Product Description

Martin Saber Tooth® 50BTB24H is a tapered bushed type B single pitch roller chain sprocket. It features hardened teeth for durability and measures five point one hundred twenty-two inches in outside diameter. This sprocket is designed for #50 chain with twenty-four teeth and a five-eighth inch pitch.

• Tapered bushing provides a strong connection to the shaft.
• Manufactured from high carbon steel for long-lasting performance.
• Designed for precise alignment and spacing of chain rows.

Product Highlights

The Martin Saber Tooth® sprocket ensures effective power transmission and is ideal for various industrial applications.

Product Information

Standard Information

• Manufacturer: Martin Sprocket & Gear
• Part Number: 50BTB24H

Technical Specifications

• Type: Taper Bushed Type B
• Chain Size: #50
• Number of Teeth: 24
• Pitch: 5/8 in
• Outside Diameter: 5.122 in
• Hub Diameter: 3.563 in
• Length Through Bore: 1-1/4 in
• Pitch Diameter: 4.788 in
• Material: Steel
• Bushing Type: 2012 Taper Lock
• Country of Origin: US
• Standards: PROP65 Warning: This product contains chemicals known to cause cancer and birth defects.
