Martin 35BS175/8 Bored to Size Sprocket - 35 / 3/8 in

Product Description

The Martin 35BS175/8 is a bored to size sprocket designed for mechanical power transmission. This sprocket features a bore diameter of zero point six two five inches and has seventeen teeth, ideal for standard roller chain applications. The product is manufactured from high carbon steel, ensuring durability and reliability in various mechanical systems.

• Compatible with 35 / 3/8 inch chain types
• Precision machined for a consistent finish
• Keyways and setscrews included for secure mounting

Product Highlights

This sprocket is suited for shaft-ready machinery, making installation straightforward. The tolerances meet or exceed ANSI standards.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• MPN: 35BS175/8
• Bore Diameter: 0.6250 inches
• Number Of Teeth: 17
• Pitch Diameter: 2.0408 inches
• Outside Diameter: 2.2310 inches
• Hub Diameter: 1.5938 inches
• Length Through Bore: 0.7500 inches
• Tooth Width: 0.168 inches
