Martin 35BS15HT1/2 Sprocket - 35 / 3/8 in Finished Bore 0.5000 in Bore 15 Teeth With Hardened Teeth

Product Description

The Martin 35BS15HT1/2 is a finished bore sprocket designed for use in mechanical power transmission systems. It features a bore diameter of half an inch and includes fifteen teeth. Constructed from high carbon steel, this sprocket comes with hardened teeth for increased durability and performance.

• Finished bore design with 0.5000 inch diameter
• Includes fifteen teeth for effective power transmission
• Manufactured from steel for strength and longevity

Product Highlights

This sprocket is ideal for applications that require reliable and efficient power transfer. It is compatible with chain number 35, which is a common specification in various machinery. The hardened teeth enhance its lifespan while maintaining precise machining tolerances.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• Weight: 0.33 lbs
• Material: Steel
• Bore Type: Finished Bore
• Pitch Type: Single
• Keyway Size: No Keyway
• Tooth Width: 0.1680 in
• Hub Diameter: 1.3438 in
• Product Type: Finished & Machinable Bore Roller Chain Sprockets
• Bore Diameter: 0.5000 in
• Number Of Teeth: 15
• Outside Diameter: 1.9890 in
• Length Through Bore: 0.7500 in
• Maximum Bore Diameter: 1 in
