Martin 22H200SD Reborable Timing Pulley

Product Description

The Martin 22H200SD is a reborable timing pulley designed for effective engagement with timing belts. It features evenly spaced grooves that minimize friction, allowing for smooth operation. This pulley is suitable for various applications, including mixers, conveyors, and pumps.

• Bushing series: SD
• Compatible with standard belts with a pitch diameter of three point five zero one inches
• Outside diameter is three point four four nine inches

Product Highlights

The Martin 22H200SD provides reliable performance without the need for lubrication.

Product Information

Standard Information

• Brand: Martin
• Part Number: 22H200SD

Technical Specifications

• Belt Pitch: 0.5 inches
• Belt Width: 2 inches
• Number of Teeth: 22
• Material: Steel
• Weight: 2.5 LB
• Bore Range Minimum: 0.5 inches
• Bore Range Maximum: 2 inches
• Bushing Type: Quick Disconnect
