Mars STD296-2UA-OB Standard Series 2 Air Curtain 96 inches Unheated

Product Description

The MARS STD296-2UA-OB Standard Series 2 Air Curtain reduces energy costs and consumption while creating effective environmental separation. It maintains interior building temperature and minimizes dirt, dust, and fumes. This air curtain prevents flying insects from intruding and offers an unobstructed view, enhancing safety. It features durable metal construction with a corrosion-resistant powder-coated finish.

• Reduces energy costs and consumption
• Creates effective environmental separation
• Maintains interior building temperature
• Prevents flying insects from intruding

Product Highlights

This 96" unheated air curtain is easy to install, requires low maintenance, and is suitable for doors up to 10 ft high.

Product Information

Standard Information

• Brand: MARS
• Manufacturer Part Number: STD296-2UA-OB
• Country of Origin: USA

Technical Specifications

• CFM: 5100 CFM
• Type: Standard
• Brand: Mars
• Phase: 1
• Series: STD2 Series
• Voltage: 115 V
• Decibels: 68
• Material: Galvanized Steel
• Horsepower: 1/2 HP
• Heating Option: Unheated
• Door Width: 96 in
• Full Load Current: 10.2 A
• Number of Motors: 2
• Door Height: 10 ft
• Max Door Height: 10 ft
• Manufacturers Part Number: STD296-2UA-OB
• Frequency: 60 Hz
• Depth: 12.75 in
• Width: 96 in
• Height: 10.62 in
• Max. RPM: 1,750 RPM
• Motor HP: 1/2 hp
• Standards: ETL
• Drive Type: Direct Drive
• Motor Type: Permanent Split Capacitor
• Housing Color: Black
• Maximum Speed: 1,750 RPM
• Nominal Voltage: 120V AC
• Maximum Air Volume: 2,884 cfm
• Sound Level @ 10 ft: 68 dBA
• Maximum Air Velocity: 4,247 fpm
• Power Consumption: 1,100 W
• Air Curtain Air Volume: 2884
• Air Curtain Air Velocity: 2550 fpm
• Amps: 10.2
• Application: Walk-In Coolers
• ETL Listed: Yes
• Exterior Color: Black
• Max Environmental Separation Height: 12 Feet
• Max Insect Blocking Height: 10 Feet
• Power: Electric
• Volts: 115 Volts
• Wattage: 1,100 Watts
• Voltage Rating: 115/1/60
• Air Flow Certified (AMCA): Yes
• Uniformity (%): 85
• Wind Stopping Capability (MPH): 12
• Nozzle Width (inches): 96
• Unit Width (inches): 96
• Unit Height (inches): 10.625
• Air Volume (CFM): 2884
• HP: 1/2 HP
