Mars B52 Classical Wrapped V-belt B Section 52 in

Product Description

The MARS B52 is a classical wrapped V-belt designed for power transmission in HVAC, refrigeration, and general mechanical drive applications. Manufactured under the Gates Hi-Power II line, it features a B-section profile with a top width of 0.66 inches and a thickness of 0.41 inches. The outside length is 52 inches. The classical wrapped construction provides consistent grip and flexibility across a wide operating temperature range of -30 to 140 degrees F. Licensed HVAC technicians and mechanical service pros rely on this belt type to maintain blower and fan drive systems in residential and light commercial equipment.

This belt is suited for B-section sheave drives found in air handling units, condensing units, and belt-drive blower assemblies. The B-section designation corresponds to a standardized cross-section, making it straightforward to source as a direct replacement during scheduled maintenance or emergency service calls. It fits single or multiple groove sheave configurations that accept the B-series profile.

Key Features

• Classical wrapped construction for reliable grip and long service life
• B-section profile with 0.66-inch top width and 0.41-inch thickness
• 52-inch outside length for standard B-series drive configurations
• Rated for operation from -30 to 140 degrees F
• Standardized cross-section for easy cross-reference and replacement

Compatibility

Designed as a direct replacement for B-section classical V-belt drives in residential and light commercial HVAC, refrigeration, and mechanical power transmission systems using standard B-series sheaves.

Installation Notes

Installation is typically performed by licensed HVAC technicians or qualified mechanical service personnel. Disconnect and lock out all power to the unit before removing or installing belts. Adjust sheave center distance to allow belt seating without forcing, then set tension according to equipment manufacturer specifications. Inspect sheaves for wear, misalignment, and debris before installing the new belt.

Technical Specifications

• Section: B
• Type: Classical Wrapped
• Outside Length: 52 inches
• Top Width: 0.66 inches
• Thickness: 0.41 inches
• Temperature Range: -30 to 140 degrees F

Standard Information

• Brand: MARS
• Manufacturer Part Number: B52
