Mars 22731 condenser fan motor 3/4 HP (1 pack)

Product Description

Mars 22731 is a 3/4 HP PSC condenser fan motor rated for 208-230 V single-phase operation, producing 1,075 RPM and intended for refrigeration and condenser fan applications. The motor has a TEAO enclosure with thermal protection, ball bearings, a double full-flatted 1/2-inch shaft (6.5 in. length) and a water slinger. It supports vertical shaft up or shaft down mounting with Rheem-style holes and belly band/extended studs. Capacitor not included.

• 3/4 HP PSC motor, 208-230 V, 60 Hz, single phase, 1,075 RPM
• Vertical shaft up or shaft down; weep holes in each end shield; Rheem mounting holes with screws; belly band and extended clamp bolts
• Thermally protected TEAO enclosure; ball bearings; double full-flatted 1/2-inch shaft; capacitor not included (rating listed as 10/370)

Product Highlights

Designed for condenser and refrigeration fan use; rated to 60°C ambient; 32 in. lead length; service factor 1.0; continuous duty.

Product Information

Standard Information

• Brand: MARS (MOTORS & ARMATURES)
• Manufacturer Part Number: 22731
• Country of Origin: China
