Magnaloy Coupling Co. M324872B Horizontal Pump/Motor Mount Adapter

Product Description

The Magnaloy Coupling Co. M324872B is a horizontal pump/motor mount adapter. It offers reliable alignment between hydraulic pumps and electric motors. This adapter is constructed from machined aluminum, making it durable. The design allows for either a SAE two-bolt or SAE four-bolt mount.

• Compatible with motor frames 324TC/TSC-405TC/TSC and 324UC/USC-405UC/USC
• Horizontal mounting type for easy installation
• Lightweight aluminum construction

Product Highlights

This adapter simplifies pump and motor setups, ensuring proper alignment.

Product Information

Standard Information

• Brand: Magnaloy Coupling Co.
• Part #: 100439730

Technical Specifications

• Pump Flange Type: SAE
• Axial Clearance: 7 7/8 inches
• Motor Frame: 324TC/TSC-405TC/TSC, 324UC/USC-405UC/USC
• Pump Flange: SAE B
• Pump/Motor Mount Length: 8 3/4 inches
• Motor Mount Holes: 4
• Radial Clearance: 7.74 inches
• Mounting Type: Horizontal
• Material: Aluminum
• Weight: 5.0 LB
