M.a. Ford. 30013600 Circuit Board Drill Bit Size 29

Product Description

The M.A. FORD. 30013600 is a solid carbide circuit board drill bit designed for precision drilling in printed circuit board (PCB) fabrication and similar close-tolerance work. Built to wire gauge size 29, it measures 0.1360 inches (3.45 mm) in diameter with a matching 3.45 mm shank diameter. The 118-degree drill point and fast spiral flute geometry promote clean entry and efficient chip evacuation. With a flute length of 0.75 inches and an overall length of 1.5 inches, this compact bit is suited for the tight clearances found in circuit board drilling fixtures and CNC drilling machines. It is installed and operated by electronics assembly technicians, PCB fabricators, and precision machining professionals.

This bit is designed for drilling cast iron, non-ferrous metals, and plastics, making it useful across PCB production, light metalworking, and prototype fabrication environments. The fast spiral (35-degree helix angle) moves chips away from the cutting zone efficiently, which is especially important in stack drilling operations common to PCB shops. The tapered web configuration adds point stability during entry, reducing walkout on flat or lightly fixtured workpieces. This is a single-piece, right-hand cutting bit appropriate for use in CNC drilling equipment or high-speed manual drill presses.

Key Features

• Solid carbide construction for extended tool life in abrasive and hard materials
• Wire gauge size 29 at 0.1360 inches (3.45 mm) diameter for precision hole sizing
• 118-degree drill point angle for balanced cutting across metals and plastics
• Fast spiral with 35-degree helix angle promotes rapid chip evacuation
• Tapered web configuration improves point stability and reduces drill walkout
• Uncoated finish suitable for applications where coatings may contaminate sensitive substrates

Compatibility

Designed as an OEM-style replacement or direct-use circuit board drill bit for CNC and manual drilling equipment accepting a 3.45 mm shank diameter in the Series 300 product line.

Installation Notes
