Lutze A3091812 Silflex Control Cable 600 VAC

Product Description

The LUTZE A3091812 is a control cable, unshielded, with a 600 VAC voltage rating. It features 12 conductors made of bare stranded copper, each with an 18 AWG conductor size and 19/30 strands. The cable has PVC/Nylon insulation, a PVC jacket, and an outside diameter of 1/2 inch. It is designed to withstand temperatures from -40 to 90 deg C.

• Flexible wires with nylon for better resistance to pressure and impacts as per UL 1277
• Easy stripping and fast installation
• Very flexible for complex installation distances and small bending radii

Product Highlights

This control cable is ideal for machine and device construction, HVAC, and environments requiring oil resistance and direct burial.

Product Information

Standard Information

• Brand: LUTZE
• Manufacturer Part Number: A3091812
• Country of Origin: USA

Technical Specifications

• Strands: 19/30
• Jacket Color: Gray
• Conductor Size: 18 AWG
• Conductor Type: Bare Stranded Copper
• Voltage Rating: 600 VAC
• Jacket Material: PVC
• Outside Diameter: 1/2 in
• Temperature Rating: -40 to 90 deg C
• Insulation Material: PVC/Nylon
• Number of Conductors: 12
• Cable Type: Control Cable, PVC
• Series: SILFLEX
• Brand: LUTZE
• Part Number #: A3091812
