Lovejoy L110HUB15T16/32 L Type Jaw Coupling Hub

Product Description

The Lovejoy L110HUB15T16/32 is a standard shaft-to-shaft connection hub designed for general industrial applications. This L Type jaw coupling hub features a sintered iron construction for durability. It includes a Centraloc spline locking feature for secure fastening.

• Standard shaft-to-shaft connection.
• Includes Centraloc spline locking feature.
• Constructed from sintered iron.

Product Highlights

This coupling hub is suitable for use in various industrial settings, providing reliable performance.

Product Information

Standard Information

• Brand: Lovejoy
• MPN: L110HUB15T16/32

Technical Specifications

• Outside Diameter: 3.32 inches
• RPM [Max]: 5000 rpm
• Lock Type: Setscrew
• Length Through Bore: 1.68 inches
• Spline Description: 16/32
• Hub Diameter: 3.32 inches
• Material: Sintered Iron
• Number of Teeth: 15
• Overall Length: 4.22 inches
• Spline Size: 15T 16/32 DP
• Coupling Size: 110, L110
• RPM: 1800 rpm
• Coupling Type: Jaw
• Weight: 2.95 lb
• EAN or UPC: 685144379115
