Lovejoy 68514428876 L090 HUB 9/16 1/8X1/16 KW LOV

Product Description

The Lovejoy 68514428876 is a type L style 1 jaw coupling hub designed for various mechanical applications. It features a bore diameter of nine-sixteenths inches and a hub diameter of two point eleven inches. The through bore length is zero point eighty-two inches, making it suitable for different shaft sizes. This coupling hub is made of sintered iron which provides strength and durability.

• Fail-safe design allows continued performance if elastomer fails
• Metal to metal contact is eliminated
• Resistant to oil, dirt, moisture, and grease

Product Highlights

This coupling can handle maximum speeds of up to nine thousand rpm and offers over eight hundred fifty thousand combinations of bore sizes for versatile applications.

Product Information

Standard Information

• Type: Type L Style 1
• Manufacturer: Lovejoy

Technical Specifications

• Bore Diameter: 9/16 in
• Hub Diameter: 2.11 in
• Hub Length: 1.32 in
• Keyway Size: 1/8 in W x 1/16 in D
• Length Through Bore: 0.82 in
• Material: Sintered Iron
• Maximum Speed: 9000 rpm
• Screw Size: 1/4-20
