LLOYD INDUSTRIES 75AH18X8 Fire Damper

Product Description

The LLOYD INDUSTRIES 75AH18X8 is a fire damper designed for HVAC systems. It is suitable for installation in walls, floors, and partitions with fire resistance ratings under two hours. This model carries a 1-1/2 hour UL fire damper label. The damper is made with a galvanized steel frame and blades, providing durability and corrosion resistance. It features a stainless steel closure spring and a fusible link that activates at one hundred sixty-five degrees Fahrenheit, automatically closing the damper in case of fire.

• Fire resistance rated for one and a half hours
• Made with twenty-two gauge galvanized steel frame and blades
• Includes a fusible link that activates at one hundred sixty-five degrees Fahrenheit

Product Highlights

This fire damper meets safety standards and ensures reliable performance in critical applications.

Product Information

Standard Information

• Brand: LLOYD INDUSTRIES
• MPN: 75AH18X8

Technical Specifications

• Fire Rating: 1-1/2 hours
• Frame Material: 22 Ga. galvanized steel
• Blade Material: 22 Ga. galvanized steel
• Closure Spring: Stainless steel
• Fusible Link Temperature: 165°F
• Mounting: Horizontal or Vertical
• Duct Size: 18 Inch width x 8 Inch height
