Littelfuse LLSRK010ID RK1 Dual-Element Time-Delay Fuse 10 A (13/16 in x 5 in)

Product Description

Littelfuse LLSRK010ID is a POWR-GARD LLSRK_ID series Class RK1, dual-element current-limiting time-delay fuse with an indicating window. It is rated 10 A at 600 VAC / 300 VDC and provides 200 kA interrupting at 600 VAC and 20 kA at 300 VDC. The cartridge fuse features ferrule terminals for holder mounting, a 13/16 in diameter x 5 in fiberglass body, granular quartz filling, plated end caps, precision-formed short-circuit element, and an elastomeric silicone overload section.

• 10 A continuous rating; voltage rating 600 VAC / 300 VDC; interrupting rating 200 kA (600 VAC) and 20 kA (300 VDC)
• Indicating window for visual blown-fuse identification; dual-element time-delay (slow-blow) characteristic
• Cartridge construction with ferrule terminals for holder mounting; fiberglass body (13/16 in Dia x 5 in L) and granular quartz filling

Product Highlights

Class RK1, 10 A time-delay indicating cartridge fuse; 600 VAC/300 VDC; 200 kA/20 kA interrupting; 13/16 in x 5 in dimensions

Product Information

Standard Information

• Brand: LITTELFUSE
• Manufacturer Part Number: LLSRK010ID
• Country of Origin: Mexico

Technical Specifications

• Manufacturer: Littelfuse
• MPN: LLSRK010ID
• Brand: Littelfuse
• Series: LLSRK
• Family: POWR-GARD LLSRK_ID
• Class: RK1
• Element: Dual (dual-element)
• Indicating: Yes (indicating window)
• Amperage Rating: 10 A
• Voltage Rating: 600 VAC / 300 VDC
• Interrupting Rating: 200 kA at 600 VAC; 20 kA at 300 VDC
• Body Type: Cartridge
• Body Size: 13/16 in Dia x 5 in L
• Material: Fiberglass reinforced pultruded body
• Terminal Type: Ferrule
• Mounting Type: Holder (fuse block/clip/holder)
• Filling: Granular quartz filling
• End Caps: Plated end caps
• Overload Section: Elastomeric silicone overload section
• Short-Circuit Element: Precision-formed short-circuit element
• Function: Current limiting, time-delay (slow-blow)
• Standards/Approvals: UL 248-12; UL File No. E81895; CSA LR29862; Federal Specification WF-1814
• Applications: General purpose circuits, motor starters, motors, transformers, safety upgrades
• UPC: 079458055252
• Country of Origin: Mexico
