LITTELFUSE FLNR01.8 UL CLASS RK5 DUAL-ELEMENT TIME-DELAY FUSE 1.8 A

Product Description

The LITTELFUSE FLNR01.8 is a UL Class RK5 dual-element time-delay fuse. It has a current rating of 1.8 A and a voltage rating of 250 VAC and 125 VDC. This fuse is designed for reliable protection against overcurrents and short circuits, making it suitable for various electrical applications.

• Reliable for interrupting overcurrents up to 200 kA
• Fast-acting for short circuit protection
• Precision manufactured for consistent response during overloads

Product Highlights

This fuse is essential for applications like service entrance switches, transformers, and motor control circuits. It meets UL standards and provides reliable performance in both industrial and commercial settings.

Product Information

Standard Information

• Manufacturer: LITTELFUSE
• Series: FLNR

Technical Specifications

• Amperage Rating: 1.8 A
• Voltage Rating: 250 VAC / 125 VDC
• Body Size: 9/16 in Dia x 2 in L
• Body Type: Cylindrical
• Class: RK5
• Element: Dual
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 200/20 kA
• Response Time: 10 s
• Terminal Type: Ferrule
• Mounting Type: Holder
• Material: Fiber
• Indicating/Non-Indicating: Non-Indicating
• Rejection/Non-Rejection: Rejection
