Lift-all EN2601DX6 Endless Polyester Sling 4800 Lb

Product Description

The LIFT-ALL EN2601DX6 is a Type 5 endless round sling constructed from polyester webbing for general rigging and lifting applications. It measures 1 inch wide and 6 feet long, with a vertical working load limit of 4,800 pounds, a choker rating of 3,800 pounds, and a basket rating of 9,600 pounds. The two-ply construction provides durability while keeping the sling lightweight and flexible. The yellow color coding follows standard sling identification conventions. Rated for use up to 200 degrees F, this sling is well suited for environments where load protection and chemical resistance are priorities. Licensed riggers and rigging crews are the primary installers and users of this product.

This endless sling is designed for use in industrial, construction, and warehouse lifting operations where a loop configuration is required. The endless design eliminates hardware hooks at the eyes, reducing contact stress on delicate or finished loads. It is appropriate for use with overhead cranes, hoists, and other lifting equipment in both single-leg vertical and basket hitch configurations. The twisted eye profile allows the sling to seat properly on hooks and lifting points without bunching.

Key Features

• 4,800 lb vertical working load limit, 3,800 lb choker, 9,600 lb basket hitch
• Type 5 endless construction — no end hardware, continuous loop design
• Two-ply polyester webbing rated to 200 degrees F maximum service temperature
• Abrasion-resistant material extends service life in high-contact applications
• Yellow color coding for quick working load limit identification on the job
• Meets OSHA 1910.184, ASME B30.9, and WSTDA standards

Compatibility

Designed as an OEM-style endless round sling for use with standard overhead cranes, hoists, and rigging hardware accepting a 1-inch wide polyester loop sling in vertical, choker, or basket hitch configurations.

Installation Notes

Rigging operations using this sling must be performed by a qualified or competent rigger in accordance with OSHA 1910.184 and ASME B30.9. Inspect the sling before each use for cuts, abrasion, discoloration, or distortion and remove from service immediately if any damage is found. Never exceed the rated working load limit for the hitch configuration in use. Do not use the sling in contact with sharp edges without appropriate corner protection.
