Description

Product Description

The LG SQA038KAZ is a hermetic scroll compressor rated at 37,000 BTU for 208-230 VAC, single-phase, 60 Hz refrigeration and air conditioning systems. It supports R-22 and R-407C refrigerants, uses a 3/4" suction and 1/2" discharge connection, and measures on a 7.5" x 7.5" mounting footprint. Internal protections include discharge temperature protection, internal pressure relief, and motor overload sensing.

  • 37,000 BTU capacity; input voltage 208-230 VAC, single-phase, 60 Hz; 3.0 HP nominal
  • Compatible with R-22 and R-407C refrigerants; suction 3/4" OD (sweat or braze); discharge 1/2" OD
  • Mounting footprint 7.5" x 7.5"; rated load amps (RLA) 15; UL listed; includes DTS, IPR, and OLP protections

Product Highlights

37,000 BTU hermetic scroll compressor for R-22/R-407C systems, 208-230 VAC single-phase, 7.5 x 7.5 in mounting, 3/4" suction and 1/2" discharge

Product Information

Standard Information

  • Brand: LG
  • Manufacturer Part Number: SQA038KAZ
  • Country of Origin: South Korea
Technical Specifications
MPN
SQA038KAZ
Brand
LG
Compressor Type
Scroll
Compressor Housing
Hermetic
BTU Output
37,000 BTU
Horsepower
3.0 HP
Input Voltage
208-230 VAC
Phase
Single
Frequency
60 Hz
Refrigerant
R-22; R-407C
Rated Load Amps (RLA)
15
Suction Line Size (OD)
3/4"
Discharge Connection Size (OD)
1/2"
Suction Line Fitting Type
Sweat or Braze
Mounting Dimensions
7.5" x 7.5"
Dimensions (H x L x W)
23.5 x 10.5 x 11 in
Unit Weight
61.5 lb
UL Listed
Yes
Evaporating Temperature Reference
45°F (7.22°C)
Condensing Temperature Reference
129.92°F (54.4°C)
Run Capacitor
50/440
Power Rating (Cooling/Input)
10,844 W (cooling); 3,333 W (input)
EER / COP
EER 11.1; COP 3.25
Discharge Orientation
Horizontal
Application
Residential and light commercial air conditioning and heat pump systems
Country of Origin
KOR
GTIN / UPC
00822529680613 / 822529680613
Additional Protections
Discharge temperature protection (DTS); internal pressure relief (IPR); internal motor overload protection (OLP); check valve to minimize reverse rotation
