Lg ebr30106401 Pcb Sub Assembly

Product Description

The LG ebr30106401 is a printed circuit board sub assembly designed for use in LG appliance and equipment systems. PCB sub assemblies serve as secondary control boards that support or extend the function of a main control board, managing auxiliary signals, relays, or interface communication within the unit. This board is an OEM-replacement part intended for installation by qualified technicians familiar with electronic component service and board-level diagnostics. It is a direct-fit replacement that restores original system performance when the existing sub board has failed or become damaged.

This PCB sub assembly is suited for residential or light-commercial LG systems where the original ebr30106401 board has been identified as the failed component. Typical install scenarios include appliance repair where the unit shows control faults, unresponsive inputs, or communication errors between the main and sub boards. A technician should confirm the board is the root-cause failure before ordering, using a wiring diagram and multimeter to rule out upstream faults.

Key Features

• OEM LG sub assembly PCB for direct replacement of failed or damaged secondary control boards
• Supports auxiliary control and signal relay functions within the host system
• Factory-matched to LG system architecture for plug-and-play connector fitment
• Designed for technician-level service and board-swap repairs

Compatibility

Designed as an OEM-style replacement sub PCB assembly for LG systems originally equipped with part number ebr30106401. No additional compatible model numbers were provided in the available product data. Verify fitment against the unit model number and wiring diagram before installation.

Installation Notes

PCB sub assembly replacement should be performed by a qualified appliance or electronics technician. Disconnect all power to the unit at the breaker before beginning any board-level service. Handle the board by its edges to avoid electrostatic discharge damage to components. Confirm all harness connectors are fully seated and locked after installation before restoring power.

Technical Specifications

• Assembly Type: PCB Sub Assembly

Standard Information

• Brand: LG
• Manufacturer Part Number: ebr30106401
