Leviton 16341-I Decora 5-20R Duplex Receptacle 20A

Product Description

The LEVITON 16341-I is a Decora-style 5-20R duplex receptacle rated for 20 amps at 125 volts, designed for commercial and residential electrical installations requiring a smooth, flush faceplate profile. This outlet accepts standard 5-15 and 5-20 plug configurations, making it compatible with a wide range of cord-connected equipment. Electricians install this receptacle in branch circuits where 20-amp capacity is required, such as kitchens, laundry areas, workshops, and commercial office or retail environments. The Decora form factor integrates cleanly with matching decorator-style wall plates and switches.

This receptacle is suited for 20-amp branch circuits in both residential and light commercial applications. Common install scenarios include countertop circuits in kitchens and break rooms, dedicated circuits for power tools, and general-purpose 20-amp outlet runs in commercial build-outs. Its standard back-wire and side-wire termination options give electricians flexibility during rough-in and trim-out stages.

Key Features

• 5-20R configuration accepts both 5-15 and 5-20 plug types
• Decora form factor for flush, modern faceplate appearance
• 20-amp, 125-volt rating suitable for dedicated branch circuits
• Compatible with standard Decora decorator wall plates
• Designed for residential and light commercial wiring applications

Compatibility

Designed as an OEM-style replacement or new-construction fit for standard single-gang electrical boxes accepting Decora-style devices.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. Always de-energize the circuit at the breaker panel and verify with a non-contact voltage tester before beginning work. Secure all wire terminations fully before seating the device in the box. Do not exceed the receptacle rated ampacity on the connected branch circuit.

Technical Specifications

• Configuration: 5-20R
• Amperage: 20 amps
• Voltage: 125 volts
• Style: Decora
• Package Dimensions (L x W x H): 20 inches x 7.6 inches x 10 inches
• Package Weight: 17.8 pounds
• UPC: 07847747363

Standard Information

• Brand: LEVITON
• Manufacturer Part Number: 16341-I
