Legris 0124 12 00 40 Compression Tube Sleeve 12mm

Product Description

The LEGRIS 0124 12 00 40 is a compression tube sleeve fitting designed to join two compression-end tube connections in a single inline body. Constructed from steel, this sleeve provides a secure, leak-resistant joint suitable for pneumatic and fluid distribution lines operating at pressures up to 320 psi and temperatures ranging from -40 degrees F to 210 degrees F. It carries multiple regulatory certifications including ATEX, PED, REACH, RoHS, and WEEE, making it appropriate for both standard and hazardous-location installations. Licensed plumbers, pipefitters, and industrial maintenance technicians are the primary installers of this fitting type.

This compression sleeve is suited for use in industrial fluid and pneumatic systems where inline tube joining is required without threading or soldering. The 12mm outside diameter sizing is common in European-standard and metric tubing runs found in manufacturing, process, and HVAC equipment. Its all-steel construction supports demanding environments where plastic fittings would not meet pressure or temperature requirements.

Key Features

• Steel construction for high-pressure and high-temperature service
• Compression x compression end connections for tool-free tube insertion and secure retention
• 12mm tube outside diameter compatibility
• Maximum working pressure of 320 psi
• Rated operating range from -40 degrees F to 210 degrees F
• Certified to ATEX, PED, REACH, RoHS, and WEEE standards

Compatibility

Designed as an OEM-style inline compression sleeve for metric tubing with a 12mm outside diameter in industrial pneumatic and fluid distribution systems.

Installation Notes

Installation is performed by qualified pipefitters or industrial maintenance technicians. De-energize and depressurize the system fully before disassembling any tubing connection. Ensure tubing ends are cut squarely and deburred before insertion into the compression fitting to achieve a proper seal. Verify that the selected tubing material and wall thickness are compatible with the fitting body before pressurizing the system.
